Customizable Carbon Steel Ultrasonic Vibrating Screen 500 Mesh

Brand Name : DY

Model Number : DYC-800

Certification : CE

Place of Origin : China

MOQ : 1

Price : 2600

Payment Terms : MoneyGram,Western Union,T/T,D/A,D/P,L/C

Supply Ability : 1-8unit/7-15Days

Packaging Details : Wooden Package

Delivery Time : 7-15 work days

Contact Now

Customizable carbon steel or stainless steel ultrasonic vibrating screen for powder sieving

Product Display

Customizable Carbon Steel Ultrasonic Vibrating Screen 500 Mesh

Product Introduction of Ultrasonic Vibrating Screen
The ultrasonic round rotary vibrating screen is consisit of the ultrasonic generator, transducer, resonant ring, vibration motor, screen body. The ultrasonic generator creates high frequency oscillation, and transducer will convert it to the high frequency sine shaped longitudinal oscillatory wave, then the oscillatory will be transmissed to the resonant ring and creates the sympathetic vibration, and the resonant ring will transmissed the vibration to the screen surface evenly. In this case, based on

the low frequency three dimensionl movement and supersonic vibration wave, the machine can not only keep off the screen mesh jam but also can improve the sieving capacity and quality.

Product Parameters

Model	Power (kw)	Valid Diameter (mm)	Layer (s)
DYC-600	0.55	550	1-3 layers
DYC-800	0.75	750
DYC-1000	1.1	950
DYC-1200	1.5	1150
DYC-1500	2.2	1450
DYC-1800	3	1750

Customer Case

Product Description

Advantages1.Small size, light weight, saving space. 2.The direction of the discharge port can be adjusted, coarse and fine material automatically discharged. 3.No mesh plug, no powder flying, the smallest screen can be up to 500 mesh (28 microns), the smallest filter up to 5 microns. 4.Single layer rotary vibration screen with unique grid design, long-term use of screen, easy to change screen mesh, only 3-5 minutes, simple operation, easy to clean. 5.No mechanical action, easy maintenance, can be single or multi-layer, contact part of the material is made of stainless steel (except for medical use). 6.Any solid, liquid, powder, granules, slurry materials within a certain range can be screened.

Recommend Products

Company Profile

Product packaging

FAQ

1).MOQ require? Our moq is 1 set.(If you need the spare parts,it is also ok).
2).Payment method?
Usually,we accept T/T,Western Union and others, we can't accept D/P,D/A

3).How to guarantee the quality?
If any machine quality problems, we accept return cargos. Our warrantity is 18 months, promise your 0 risks purchasing
